KF2-A 3000-150-146-NC
KF2-A for Nitro Cooler (NC ) for use with a Nitro Cooler unit.
Every time a KF2 controllable gas spring is stroked, energy is transferred from the press to the spring. The amount of energy transferred is a function of the spring force multiplied by its stroke length. KF2-NC are for use with a Nitro Cooler™.
Nitro Coolers are ideal for a small number of springs that operate at higher production rates and therefore require cooling. For applications where a Nitro Cooler is required, each KF2-NC gas spring is fitted to the Nitro Cooler.
Nitro Coolers are ideal for a small number of springs that operate at higher production rates and therefore require cooling. For applications where a Nitro Cooler is required, each KF2-NC gas spring is fitted to the Nitro Cooler.
Diagram / specifications section
Preview
| L min | Minimum Length (in) | 11.5 |
| S | Stroke Length (in) | 5.75 |
| L | Total Length (in) | 17.24 |
Item specifications
- End Force At Full Stroke (LBF)9400
- Force Increase By Temperature Percent Per (°F)0.17
- Gas Volume (CuF)0.040611867
- Initial Force at max. pressure (lbf) 6744
- Max Charging Pressure (Psi)2175
- Max Piston Rod Velocity (FtMin)157.48
- Max. Operating Temperature (F)176
- Min Charging Pressure (PSI)362
- Min. Operating Temperature (F)32
- Recommended Max Strokes Per MinuteSee separate info.
- Weight (lb)33.968
